About Your Monitor 23
Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The monitor
automatically provides the computer with its Extended Display Identification Data (EDID)
using Display Data Channel (DDC) protocols so that the system can configure itself and
optimize the monitor settings. Most monitor installations are automatic. You can select
different settings if required.
Flat-Panel Specifications
Model number C7017T
Screen type Active matrix - TFT LCD
Panel Type Vertical Alignment
Viewable image
Diagonal 1765.63 mm (69.513 inches)
Horizontal Active Area
1538.88 mm (60.59 inches)
Vertical Active Area 865.62 mm (34.08 inches)
Active Area 1332085.31 mm
2
(2064.91 inches
2
)
Pixel pitch 0.802 x 0.802 mm
Viewing angle:
Horizontal 176° typical
Vertical 176° typical
Luminance output 380 cd/m² (typical)
Contrast ratio 3800 to 1 (typical)
Faceplate coating Antiglare with hard-coating 2H
Backlight LED light bar system
Response Time 8 ms typical (gray to gray)
Color Depth 1.07 billion colors
Color Gamut 86 % (typical) *
* C7017T color gamut (typical) is based on CIE1976 (86 %) and CIE1931 (72 %) test
standards.
