Dell Crystal - Brightness and Contrast Adjustment; Color Settings Menu

1.
Press the button to open the OSD menu and display the main menu.
Main Menu
2.
Press the and buttons to toggle between options in the Menu. As you move from one icon to another, the option name is highlighted.
3.
Toselectthehighlighteditemonthemenupressthe again.
4.
Press the and buttons to select the desired parameter.
5.
Press the buttontoentertheslidebarandthenusethe or button, according to the indicators on the menu, to make your changes.
6.
Select the to return to previous menu without accepting current settings or to accept and return to previous menu.
The table below provides a list of all the OSD menu options and their functions.
Icon
Menu and Submenus
Description
BRIGHTNESS &
CONTRAST
Use the Brightness and Contrast menu to adjust the Brightness/Contrast.




Back
Press to go back to the main menu.

Brightness
Allows you to adjust the brightness or luminance of the backlight.
Press the buttontoincreasebrightnessandpressthe button to decrease brightness (min 0 ~ max 100).

Contrast
Allows you to adjust the contrast or the degree of difference between darkness and lightness on the monitor screen. Adjust brightness
first, and adjust contrast only if you need further adjustment.
Press the button to increase contrast and press the button to decrease contrast (min 0 ~ max 100).
COLOR SETTINGS
Use the Color Settingmenutoadjustthemonitor'scolortemperature.


Color setting mode
submenu


Back
Press to go back to the main menu.

Input Color Format
Allows you to set the video input mode to.
l RGB
: Select this option if your monitor is connected to a computer ore DVD player using the HDMI cable or the HDMI to DVI adapter.
l YPbPr: Select this option if the your DVD player supports only YPbPr output.

Mode Selection
Allows you to set the display mode to:
