Replacing the full-length
graphics cards
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the full-length graphics card with the slot on the system board.
2 Place the card into the slot and press down rmly until the full-length graphics
card snaps into place.
3 Connect the power cables to the full-length graphics card.
4 Slide the tab on the graphics-card bracket into the slot on the chassis and snap it
into place.
Post-requisites
1 Follow the procedure from step 9 to step 10 in “Replacing the power-supply
unit”.
2 Replace the right-side cover.
71
