Dell DD6800 - DD6800 System Details

Table 23 Memory locations - CPU 1
Channel A Channel B Channel D Channel C
Tier Total
Memory
8 9 10 11 12 13 14 15
DD6300 AIO
Expanded
96 GB 8 GB 8 GB 8 GB 8 GB N/A 8 GB N/A 8 GB
DD6300 AIO 48 GB 8 GB N/A 8 GB N/A N/A 8 GB N/A N/A
DD6800 system features
Table 24 DD6800 system features
Feature DD6800 DLH (Base
configuration)
DD6800 DLH (Expanded configuration)
Rack height 2U 2U
Processor E5-2630 V3 E5-2630 V3
Kernel 3.2.x 3.2.x
Memory con-
figuration
Non-extended
retention
192 GB 192 GB
DD Cloud Tier N/A 192 GB
Extended retention N/A 192 GB
a
DIMMs 8x8 GB + 8x16 GB 8x8 GB + 8x16 GB
Supported
capacity
Non-extended
retention (Active tier)
144 TB 288 TB
DD Cloud Tier N/A 576 TB
b
Extended retention
(Archive tier)
N/A 288 TB
a
Stream count 405 writes, 112 reads 405 writes, 112 reads
HDDs in 3.5" bays 4 4
SSDs in 3.5" bays 2 4
SSDs in 2.5" bays 0 0
NVRAM NVRAM 8g Model 3 NVRAM 8g Model 3
High availability configuration support Yes Yes
HA Private Interconnect (2) 10GBase-T ports (2) 10GBase-T ports
External SSD shelf One SSD shelf for A-P high
availability cluster containing two
drives.
One SSD shelf for A-P high availability cluster
containing four drives.
SAS I/O modules (Quad Port 6 Gbps
SAS
2 2
Data Domain DD6300, DD6800, and DD9300 Hardware Overview
DD6800 system features 31
