Adding Parts 63
HINT: To prevent
damage to your computer,
the front door is designed
to "break away" if it is
lifted up too far. For
instructions on how to
reattach the door, see
page 64.
Windows
license label*
USB 1.1 connectors
headphone connector
service tag
*The label may be located on the side of your computer
voltage selection switch
power connector
parallel connector
keyboard connector
USB 1.1 connectors
microphone
connector
line-out
connector
line-in
connector
mouse connector
video connector
serial connector
