Adding Parts 83
10 Connect a power cable to the drive.
NOTICE: Match the colored strip on the cable with pin 1 on the drive.
11 Locate the extra connector on the drive cable that is attached to your
first hard drive and attach the connector to the second hard drive.
rail tabs (2)
second hard drive
in upper bay
hard drive cage
first hard drive in
lower bay
