Dell E1909Wc - Page 30

19" LCD Color Monitor Dell E1909Wc
30
2.Pry the monitor up
then find out the
hooks’ position, use
the tool (like the
picture or other card)
to insert into the gap
of bezel and rear
cover, then turn over
the monitor and take
off the rear cover.
Remove the key
board：
Remove the screws
remarked in red by
Torque B or by
manual
KEPC cable
