Dell E1920H - Monitor Specifications

12 │ About your monitor
Monitor specications
Model E1920H E2020H
Screen type Active matrix-TFT LCD Active matrix-TFT LCD
Panel type
TN TN
Viewable area
Diagonal
470.10 mm (18.5 in.) 494.1 mm (19.5 in.)
Pixel pitch
0.3000 mm x 0.3000 mm 0.2700 mm x 0.2700 mm
Pixel per inch (PPI)
85 94
Brightness
250 cd/m² (typical) 250 cd/m² (typical)
Contrast ratio
600 to 1 (typical) 1,000 to 1 (typical)
Tilt angle
-5° to 21° -5° to 21°
Faceplate coating Anti-glare with 3H hardness Anti-glare with 3H hardness
Height adjustable stand
Built-in Speakers
(2 x 1 W sound output)
-
-
-
-
Backlight LED light bar system LED light bar system
Color depth
16.7 million colors 16.7 million colors
Color gamut
72% (CIE1931)/83%(CIE1976)72% (CIE1931)/83%(CIE1976)
Connectivity 1 x DP1.2, 1 x VGA 1 x DP1.2, 1 x VGA
Dell display manager
compatibility
Yes Yes
Bezel width (edge of
monitor to active area)
17.8 mm (Top)
17.8 mm (Left/Right)
17.8 mm (Bottom)
18.3 +/- 0.5 mm (Top)
18.3 +/- 0.5 mm
(Left/Right)
18.3 +/- 0.5 mm (Bottom)
Security Security-lock slot for cable
lock (optional purchase)
Security-lock slot for cable
lock (optional purchase)
Active area:
Horizontal
Vertical
Area
409.80 mm (16.13in.)
230.40 mm (9.07in.)
944.18 cm² (146.30 in.²)
432.96 +/- 0.96mm (17.05 in.)
238.05 +/- 1.71mm (9.37 in.)
1025.53 cm ~ 1035.76 cm²
(158.96 in.² ~ 160.55 in.²)
Viewing angle:
Horizontal
Vertical
90° (typical)
65° (typical)
170° (typical)
160° (typical)
Response time
Normal mode
Fast mode
5 ms
-
5 ms
-
