Dell E1920H - Page 18

18 │ About your monitor
Electrical specications
Model
Model
E2420H
E2420HS
Video input signals
Video input signals
Inrush current
Inrush current
Synchronization
input signals
Synchronization
input signals
AC input voltage/
frequency/current
AC input voltage/
frequency/current
Analog RGB: 0.7 V ± 5 %,
75 Ω input impedance
DP, 600 mV
for each dierential line,
100 Ω input impedance per dierential pair
Analog RGB: 0.7 V ± 5 %,
75 Ω input impedance
HDMI 1.4 (HDCP 1.2), 600 mV
for each dierential line,
100 Ω input impedance per dierential pair
Separate horizontal and vertical synchronizations,
polarity-free TTL level,
SOG (Composite SYNC on green)
Separate horizontal and vertical synchronizations,
polarity-free TTL level,
SOG (Composite SYNC on green)
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 0.8 A
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 0.8 A
30 A (120 V AC Input)
60 A (240 V AC Input)
30 A (120 V AC Input)
60 A (240 V AC Input)
