Input requirement
● Supply voltage: – (48–60) V DC
● Current consumption: 83.2 A maximum
● Kit Contents:
1. DC-IN connector (1) per each PSU - Dell Part # PXNKY
NOTE: Each PXNKY includes 2 pieces of Panduit 2 AWG straight, 2-hole lug # LCC2-14AW-Q, for use in crimping
lug to each 2 AWG power input cable (customer provided).
2. Earth ground lug kit (1) - Dell Part # V3NR7
NOTE: Each V3NR7 includes 2 pieces of Panduit 2 AWG 90-degree 2-hole lug # LCDN2-14AF-Q and 4 x M6 nuts,
for creation of 2 earth-ground cable assemblies to connect to the rear wall.
3. Rail kit (1) - Dell Part # HC9KX
NOTE: Each HC9KX includes rail assemblies, strain-relief bar (SRB) assembly, hook-and-loop straps.
● Required Tools (customer provided)
1. Cable stripping tool – Must be capable of supporting 2 AWG stranded copper cable.
NOTE: Klein cable cutting tool # 63050 can cut 2 AWG cable and can strip insulation from same cable.
2. Cable cutting tool – Must be capable of cutting 2 AWG stranded copper cable.
3. Crimping tool – Must be capable of crimping 2 AWG cable lugs to 2 AWG stranded copper cable. Reference Panduit or
equivalent catalog for several options of manual or Lithium-Ion battery-operated hydraulic crimpers and dies capable of
supporting 2 AWG cable to 2 AWG lug crimping. Panduit catalog lists their die options, as well as alternate vendors -
Burndy and Thomas & Betts.
4. 10 mm socket or wrench (to install or remove M6 nuts within DC-IN connector).
5. 1.5 mm hex wrench (to install or remove two hex head screws that secures 3 piece DC connector housing).
● Required cables (customer provided)
○ UL 10322 - 2 AWG, black, stranded copper cable (–48V DC)
○ UL 10322 - 2 AWG, red, stranded copper cable (V DC return)
○ UL 10322 - 2 AWG, green/yellow (green with yellow stripe), stranded copper cable (safety ground)
○ Heat-shrink tubing that fits over 2 AWG stranded cable
○ Ring terminals – as required for connecting chassis cables to DC power source and to earth ground
2
Input requirement 5
