Table 11 Management B, nodes 23 -32 cabling (continued)
Source Destination
Node 30 MGMT1 Management SwitchB Port 11
Node 31 BMC (iDRAC) Management SwitchB Port 13
Node 31 MGMT1 Management SwitchB Port 15
Node 32 BMC (iDRAC) Management SwitchB Port 17
Node 32 MGMT1 Management SwitchB Port 19
Data SwitchC MGMT Port Management SwitchB Port 47
Data SwitchD MGMT Port Management SwitchB Port 48
Management Server NIC1 Management SwitchB Port 48
Link to Core Switch or Management SwitchA Management SwitchB Port 52
Install Management Network I/O Cables
48 Dell EMC VxFlex Ready Node Server Installation Guide
