Dell Force10 S25-01-GE-24P Configuration Guide

4 Basic Layer 2 Setup and Buffer Tuning of the S25P for Storage Environments
Setting Up Layer 2 Switching
The following screenshot illustrates the use of these commands (use a space before and after the hyphen):
Step Task Command Syntax Command Mode
1 Select all ports.
This example assumes that the stack ID is 0.
The prompt changes to:
Force10(conf-if-range-gi-0/1-24)#
interface range gi 0/1 - 24
(A space is required before and
after the dash in the command.)
CONFIGURATION
2 Enable the selected ports for Layer 2 switching.
switchport
INTERFACE RANGE
3 Set the maximum Link MTU (frame size) to handle
Jumbo frames.
mtu 9252
INTERFACE RANGE
4 Administratively enable all ports.
no shutdown
INTERFACE RANGE
5 Return to CONFIGURATION mode.
exit
INTERFACE RANGE
6 Repeat the above sequence for the 10GbE ports.
interface range te 0/25 - 28
CONFIGURATION
7 After physically connecting the ports, use the
show
ip interfaces brief
command to inspect
administrative status (the Status field in the output)
and link status (the Protocol field).
do show ip interfaces brief
INTERFACE RANGE
Force10(config)#interface range gigabitethernet 0/1 - 24
Force10(conf-if-range-gi-0/1-48)#switchport
Force10(conf-if-range-gi-0/1-48)#mtu 9252
Force10(conf-if-range-gi-0/1-48)#no shutdown
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/1
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/2
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/3
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/4
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/5
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/6
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/7
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/8
21:22:23: %STKUNIT0-M:CP %IFMGR-5-ASTATE_UP: Changed interface Admin state to up: Gi 0/9
! ----------------------- output truncated ------------- !
Force10#show ip interface brief
Interface IP-Address OK Method Status Protocol
GigabitEthernet 0/0 unassigned NO Manual up down
GigabitEthernet 0/1 unassigned NO Manual up down
GigabitEthernet 0/2 unassigned NO Manual up down
GigabitEthernet 0/3 unassigned NO Manual up down
GigabitEthernet 0/4 unassigned NO Manual up down
GigabitEthernet 0/5 unassigned NO Manual up down
GigabitEthernet 0/6 unassigned NO Manual up down
GigabitEthernet 0/7 unassigned NO Manual up down
GigabitEthernet 0/8 unassigned NO Manual up down
GigabitEthernet 0/9 unassigned NO Manual up down
! ----------------------- output truncated ------------- !

Dell Force10 S25-01-GE-24P Specifications

General

Form Factor	1U
Ports	24 x 10/100/1000BASE-T
VLANs	4094
MAC Address Table Size	16000 entries
Jumbo Frame Support	9216 bytes
Storage Temperature	-40°C to 70°C
Power Supply	AC
