Dell FPM185 - Signal Connector Details

11xxx | Operating the Console Trayxxx
in use. If input from the keyboard, mouse or other input devices is detected, the
monitor will automatically wakeup, unless stowed. The following table shows
the power consumption and signals for this automatic power saving feature.
VESAMode Video H-sync V-sync
Power
Used
LEDColor
On Active Yes Yes
Maximum
20W
Full bright
<blue>
Stowed
Position
Blanked No Yes <0.5W Amber
Sleep mode Blanked Yes No <0.5W Amber
Active-off Blanked No No <0.5W Amber
DC power off NA NA NA 0W Dark
Table 3.2: Power Management Modes
Pin No. Signal
1 Red Video
2 Green Video
3 Blue Video
4 NC
5 Logic Ground
6 Red Video Ground
Table 3.3: Signal Connector (15-pin D-sub Connector)
