Operating the Console Trayxxx | xxx12
Pin No. Signal
7 Green Video Ground
8 Blue Video Ground
9 VCC
10 Identify VGA Cable Connection
11 NC
12 SDA (DDC1/2B)
13 Horizontal Sync
14 Vertical Sync
15 SCL (DDC2B)
Setting up the monitor
To set up the flat-panel monitor:
1 Ensure the monitor has been connected to an ACpower source.
2 Pull the monitor tray out.
3 Hold the monitor by its handle and rotate it to a maximum 110-degree
angle.
NOTE: Use the tray's handle to push and pull the tray in the rack.
4 The first time the unit is connected to power, you must touch the power
icon to turn it on. After the first time, the unit will turn on when opened.
NOTE: If power is completely disconnected, the console tray will default into Active-Off
mode.
