166 Adding and Replacing Parts
Replacing the Card
1
Replace the card at an angle to slide it under the securing tabs in the card
compartment.
2
Connect the cable to the card.
Coin-Cell Battery
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on the back of the computer).
NOTICE: To help prevent damage to the system board, you must remove the battery
from the battery bay before you begin working inside the computer.
1 securing tabs (2) 2 cable
3card
1
3
2
