About Your Computer 33
Bottom View
LEFT SPEAKER — To adjust the volume of the integrated speaker, press the volume
control buttons or the mute button.
CONSUMER IR — Lets you transfer files from your computer to another infrared-
compatible device without using cable connections. When you receive your computer,
the sensor is disabled. You can use the system setup program (see "Using the System
Setup Program" on page 189) to enable the sensor. For information on transferring
1 left speaker 2 consumer IR
3 memory module/coin-cell battery
compartment
4 right speaker
5 wireless mini card compartment 6 battery
7 battery charge/health gauge 8 battery release latches (2)
9 air vents 10 hard drive
5
10
7
6
8
9
