Dell Inspiron 3581 User Manual

Screw list
NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and then
place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is restored when
the component is replaced.
NOTE: Some computers have magnetic surfaces. Ensure that the screws are not left attached to such surface when replacing a
component.
NOTE: Screw color may vary with the conguration ordered.
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Base cover Palm rest and keyboard
assembly
M2x2 2
Base cover Palm rest and keyboard
assembly
M2x4 1
Base cover Palm rest and keyboard
assembly
M2.5x7 6
NOTE: Screw color
may vary depending
on the conguration
ordered.
Battery Palm rest and keyboard
assembly
M2x3 4
Display panel Display back-cover and
antenna assembly
M2x2 4
Fan Palm rest and keyboard
assembly
M2.5x5 3
Hard-drive assembly Palm rest and keyboard
assembly
M2x3 4
Hard-drive bracket Hard drive M3x3 4
Heat sink System board M2x3 3
Hinges Palm rest and keyboard
assembly
M2.5x5 5
Hinge brackets Display back-cover and
antenna assembly
(M2.5x4) 8
5
Screw list 15

Dell Inspiron 3581 Specifications

General

Operating System	Windows 10 Home
Color	Black
RAM	4GB DDR4
Storage	1TB HDD
Display	15.6-inch HD (1366 x 768)
Graphics	Intel UHD Graphics 620
Battery	3-Cell 42WHr Battery
Weight	2.2 kg
Dimensions	380 x 258 x 22.7 mm (14.96 x 10.16 x 0.89 inches)
Ports	2 USB 3.1 Gen 1, 1 USB 2.0, 1 HDMI 1.4b, 1 SD Card Reader, 1 RJ-45
Wireless	802.11ac Wi-Fi
Processor	Intel Core i3/i5/i7 (8th Gen)
