Dell Inspiron 3581 User Manual

Replacing the display panel
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Place the display panel on a at and clean surface.
2 Connect the display cable to the connector at the back of the display panel and close the latch to secure the cable.
3 Adhere the tape that secures the display cable to the back of the display panel.
4 Place the display panel on the display back-cover and antenna assembly.
5 Align the screw holes on the display panel with the screw holes on the display back-cover and antenna assembly and Rreplace the
screws that secure the display panel to the display back-cover and antenna assembly.
51
Replacing the display panel 87

Dell Inspiron 3581 Specifications

General

Operating System	Windows 10 Home
Color	Black
RAM	4GB DDR4
Storage	1TB HDD
Display	15.6-inch HD (1366 x 768)
Graphics	Intel UHD Graphics 620
Battery	3-Cell 42WHr Battery
Weight	2.2 kg
Dimensions	380 x 258 x 22.7 mm (14.96 x 10.16 x 0.89 inches)
Ports	2 USB 3.1 Gen 1, 1 USB 2.0, 1 HDMI 1.4b, 1 SD Card Reader, 1 RJ-45
Wireless	802.11ac Wi-Fi
Processor	Intel Core i3/i5/i7 (8th Gen)
