Back to Contents Page
Module Cover
Dell™Inspiron™N4010ServiceManual
Removing the Module Cover
Replacing the Module Cover
Removing the Module Cover
1. Follow the instructions in Before You Begin.
2. Remove the battery (see Removing the Battery).
3. Loosen the captive screw that secures the module cover to the computer base.
4. Lift and slide the module cover out of the computer base.
Replacing the Module Cover
1. Follow the instructions in Before You Begin.
2. Slide the two tabs on the module cover into the slots on the computer base and gently snap the module cover into place.
3. Tighten the captive screw that secures the module cover to the computer base.
4. Replace the battery (see Replacing the Battery).
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: Onlyacertifiedservicetechnicianshouldperformrepairsonyourcomputer.DamageduetoservicingthatisnotauthorizedbyDell™
is not covered by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery (see Removing the Battery) before working inside the
computer.
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
To Next Page
