Thermal Fan
Dell™Inspiron™N4010ServiceManual
Removing the Thermal Fan
Replacing the Thermal Fan
Removing the Thermal Fan
1. Follow the instructions in Before You Begin.
2. Remove the battery (see Removing the Battery).
3. Follow the instructions from step 3 to step 4 in Removing the Optical Drive.
4. Remove the module cover (see Removing the Module Cover).
5. Remove the memory module(s) (see Removing the Memory Module(s)).
6. Remove the keyboard (see Removing the Keyboard).
7. Remove the palm rest (see Removing the Palm Rest).
8. Disconnect the I/O board cable and the thermal fan cable from the connectors on the system board.
9. Remove the two screws that secure the thermal fan to the computer base.
10. Lift the thermal fan along with the cable, off the computer base.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: Onlyacertifiedservicetechnicianshouldperformrepairsonyourcomputer.DamageduetoservicingthatisnotauthorizedbyDell™
is not covered by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
