Back View
1
display 2 volume controls
3 power button 4 ambient light sensor
5 network connector 6 USB connector
7 IEEE 1394 connector 8 memory card reader
9 keyboard 10 Wi-Fi Catcher™ Network Locator
11 wireless switch 12 fingerprint reader (optional)
13 touchpad 14 touchpad buttons (2)
15 device status lights 16 Dell Latitude ON™ button (optional)
17 keyboard status lights 18 camera (optional)
19 microphone (optional)
1 ExpressCard slot 2 smart card slot
3 cooling vents 4 audio connectors (2)
5 USB/eSATA connector 6 video connector
7 AC adapter connector 8 power light/battery light
9 battery 10 security cable slot
1
2
3
4
5
6
7
8
9
10
