Dell Latitude E4200 - Side View; Back View

Temperature range
Operating
0° to 35°C (32° to 95°F)
Storage -40° to 60°C (-40° to 140°F)
Coin-cell battery CR2032
AC Adapter
Type 45 W or higher
Input voltage 90–264 VAC
Input current (maximum) 1.1 A
Input frequency 47–63 Hz
Output current 3.3 A (maximum at 10 ms pulse); 2.3 A (continuous)
Rated output voltage 19.5 +/–1.0 VDC
Temperature range
Operating 0° to 35°C (32° to 95°F)
Storage -40° to 65°C (-40° to 149°F)
Physical
Height
19.95–26.82 mm (0.79–1.06 inches)
Width 290.60 mm–296.60 mm (11.44–11.68 inches)
Depth 204.00 mm–226.00 mm (8.03–8.90 inches)
Weight 1 kg (2.2 lbs)
Environmental
Temperature range
Operating 0° to 35°C (32° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity (maximum)
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
Battery (continued)
