Dell M6300 - Bottom View

14 Quick Reference Guide
Bottom View
1 battery charge/health gauge 2 battery release latch
3 battery 4 strike zone
5 cover for optional internal card with
Bluetooth
®
wireless technology
6 hard drive
7 air vent 8 mini card/modem cover
9 docking device connector 10 memory module cover
11 air vent 12 optical drive security screw
