1. Base cover 2. Battery
3. Speakers 4. Power-button with optional fingerprint-reader
5. Touchpad 6. Touchpad bracket
7. Power-adapter port 8. M.2 solid-state drive thermal plate
9. M.2 solid-state drive 10. Palm-rest and keyboard assembly
11. Display assembly 12. Memory modules
13. Wireless card with bracket 14. I/O board
15. System board 16. Heat sink
17. Fan 18. I/O board FFC
19. Hard-disk drive
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
Secure Digital (SD) Card
Removing the Secure Digital card
Prerequisites
1. Follow the procedure in Before working inside your computer.
Removing and installing components
13
