• cover
5. Follow the procedure in After Working Inside Your Computer.
Removing the optical drive
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
• cover
• bezel
3. To remove the optical drive:
a. Open the front bezel door.
b. Disconnect the data cable and power cable from the connectors on the optical drive [1, 2].
c. Close the front bezel door [3].
d. Press the blue tab to release the optical drive from the computer [4].
e. Slide the optical drive out of the computer [5].
Installing the optical drive
1. Insert the optical drive into the optical drive bay until it clicks into place.
2. Open the front bezel door.
3. Connect the data cable and power cable to the connectors on the optical drive.
4. Close the front bezel door.
5. Install the:
• bezel
• cover
6. Follow the procedure in After Working Inside Your Computer.
12
