Dell OptiPlex 3040 - Installing the Power Supply Unit (PSU); Removing the VGA Card; Installing the VGA Card

• bezel
• cover
7. Follow the procedure in After Working Inside Your Computer.
Removing the VGA card
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
• cover
• bezel
3. Open the front bezel door
4. To remove the VGA card:
a. Remove the screws that secure the VGA connector to the computer [1].
b. Slide the VGA connector to release it from the computer [2].
c. Remove the screw that secures the VGA card to the computer [3].
d. Lift the VGA card using the handle to remove it from the computer [4].
Installing the VGA card
1. Align the VGA card with the screw holder on the system board.
2. Tighten the screw to secure the VGA card to the system board.
3. Insert the VGA connector into the slot at the back of the computer.
4. Tighten the screws to secure the VGA connector to the computer.
5. Close the front bezel door.
6. Install the:
• bezel
• cover
7. Follow the procedure in After Working Inside Your Computer.
