Dell OptiPlex 3040 - Installing the Memory Module; Removing the PCIe Expansion Card

Installing the memory module
1. Align the notch on the memory module with the tab on the memory module connector.
2. Insert the memory module into the memory module socket.
3. Press the memory module until the memory module retention tabs click into place.
4. Close the front bezel door.
5. Install the:
a. cover
b. bezel
6. Follow the procedure in After Working Inside Your Computer.
Removing the PCIe expansion card
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
• cover
• bezel
3. Open the front bezel door.
4. To remove the PCIe expansion card:
a. Pull the release latch to unlock the PCIe expansion card [1].
b. Push the release tab [2] and lift the PCIe expansion card out of the computer [3].
