Table 31. Power
NOTE: Heat dissipation is calculated by using the power supply wattage rating.
Power Wattage Maximum Heat
Dissipation
Voltage
240 W 819.00 BTU/hr 100 V AC to 240 V AC,
50 Hz to 60 Hz, 4A/2A
Coin cell battery 3 V CR2032 lithium coin cell
Table 32. Physical dimension
Feature Specifications
Height 350.00 mm (13.77 inches)
Width 154.00 mm (6.06 inches)
Depth 274.00 mm (10.78 inches)
Weight 8.00 kg (17.64 lb)
Table 33. Environmental
Feature Specification
Temperature range
Operating 5°C to 35°C (41°F to 95°F)
Storage –40°C to 65°C (–40°F to 149°F)
Relative humidity (maximum)
Operating 20 percent to 80 percent (non-condensing)
Storage 5 percent to 95 percent (non-condensing)
Maximum vibration
Operating 0.26 Grms
Storage 2.20 Grms
Maximum shock
Operating 40 G
Storage 105 G
Altitude
Operating –15.2 m to 3048 m (–50 to 10,000 ft)
Storage –15.20 m to 10,668 m (–50 ft to 35,000 ft)
Airborne contaminant level G1 or lower as defined by ANSI/ISA-S71.04-1985
50
