Field service information
Topics:
• Recommended tools
•
Screw List
• Side cover
• Front bezel
• 2.5-inch hard-drive assembly
• 3.5-inch hard-drive assembly
• Hard-drive and optical-drive module
• Solid-state drive
• Optical drive
• WLAN card
• Heat sink
• Coin-cell battery
• Expansion card
• Memory modules
• Processor
• Power-supply unit
• Intrusion switch
• Optional I/O modules (Type C/ HDMI/VGA/DP/Serial)
• System board
Recommended tools
The procedures in this document may require the following tools:
● Phillips #0 screwdriver
● Phillips #1 screwdriver
● Plastic scribe-Recommended for field technician
Screw List
The following table shows the screw list and the images for different components.
Table 6. Screw list
Component Screw type Quantity Image
FIO bracket 6-32 2
M.2 2230/2280 Solid-state drive M2x3 1
WLAN card M2x3 1
Power supply unit #6-32 3
4
18 Field service information
