Steps
1. Disconnect the hard-drive data and power cables from the connectors on the 2.5-inch hard-disk drive module.
2. Press the release tabs on both the sides of the hard-drive bracket to release it from the slots on the computer chassis.
3. Tilt the hard-drive assembly slightly at an angle.
4. Lift the hard-drive assembly from the computer.
NOTE: Note the orientation of the hard drive so that you can replace it correctly.
Removing the 2.5-inch hard-drive bracket
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the side cover.
3. Remove the fan duct.
4. Remove the 2.5 inch hard-drive assembly.
18
Removing and installing components
