4 To disconnect the cables:
a Disconnect the power cable from the system board [1] [2].
b Lift the cables away from the computer [3, 4].
c Remove the screws(6lbs) that secure the PSU to the computer [5].
5 To remove the PSU:
a Press the blue release tab [1]
b Slide the PSU and lift it away from the computer [2].
Removing and installing components
33
