Chassis
Front chassis view
1 Power button and power light 2 Hard drive activity light
3 Memory card reader (optional) 4 Optical drive (optional)
5 Headset port 6 USB 2.0 port with PowerShare
7 USB 2.0 port 8 USB 3.1 Gen1 port
2
8 Chassis
