2. Install the Side cover.
3. Follow the procedure in After working inside your computer.
Hard drive
Removing the 2.5–inch drive from the drive bracket
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
a. Side cover
b. 2.5 inch hard drive assembly
3. To remove the drive bracket:
a. Pull one side of the drive bracket to disengage the pins on the bracket from the slots on the drive [1] and lift the drive
[2].
20
Removing and installing components
