Dell Optiplex 5070 Small Form Factor Service Manual

Removing and installing components
Side cover
Removing the side cover
1. Follow the procedure in Before working inside your computer.
2. To remove the cover:
a) Slide the release latch on the back side of your system until it gives a click sound to unlock the side cover [1].
b) Slide and lift the side cover from the system [2].
Installing the side cover
1. Place the cover on the system and slide the cover until it clicks into place [1].
2. The release latch automatically locks the side cover to the system [2].
3
Removing and installing components 15
