Installing the optical drive
1. Slide the optical drive into the optical drive cage.
2. Align the tabs on the optical cage with the slots on the computer.
3. Lower the optical drive cage into the computer and lock the latch.
4. Connect the data and power cables to the optical drive.
5. Install the:
a. hard drive assembly
b. front bezel
c. cover
6. Follow the procedure in After Working Inside Your Computer.
Removing the system fan
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
a. cover
b. front bezel
c. hard drive assembly
d. optical drive
3. To remove the system fan:
a. Disconnect the system fan cable from the system board [1].
b. Slide the fan grommets toward the slot on the back wall [2].
c. Lift the fan away from the computer. [3]
