Dell OptiPlex 7040 - Installing the SD card reader; Installing the optional SSD card

Installing the SD card reader
1. Place the SD card reader on the chassis.
2. Tighten the screws that secure the SD card reader to the computer.
3. Route the power supply unit cables into the retention clips.
4. Install the:
a. power supply unit
b. optical drive
c. hard drive assembly
d. front bezel
e. cover
5. Follow the procedure in After Working Inside Your Computer.
Installing the optional SSD card
1. Remove the:
a. cover
b. front bezel
2. Peel the adhesive tape (blue) from the rubber.
