Table 22. Audio
Feature Specification
Integrated Two channel High Definition Audio
Table 23. Network
Feature Specification
Integrated Intel I219-LM Ethernet capable of 10/100/1000 Mb/s
communication
Table 24. System information
Feature Specification
System chipset Intel 100 series, Q170
DMA channels Two 8237 DMA controllers with seven independently
programmable channels
Interrupt levels Integrated I/O APIC capability with 24 interrupts
BIOS chip (NVRAM) 16 MB
Table 25. Expansion bus
Feature Specification
Bus type PCIe gen3 (x16), USB 2.0, and USB 3.0
Bus speed PCI Express:
• x4-slot each direction speed – up to 3.94 GB/s
• x16-slot each direction speed–16 GB/s
SATA: 1.5 Gbps, 3.0 Gbps, and 6 Gbps
Table 26. Cards
Feature Specification
PCI express x4 Half height card
PCI express x16 Half height card
Table 27. Drives
Feature Specification
Externally accessible (5.25-inch drive bays) Two
Optical drive One
51
