Table 32. Physical dimension
Feature Specifications
Height 290.00 mm (11.42 inches)
Width 93.00 mm (3.66 inches)
Depth 312.00 mm (8.38 inches)
Weight 6.00 kg (13.22 lb)
Table 33. Environmental
Feature Specification
Temperature range
Operating 5°C to 35°C (41°F to 95°F)
Storage –40°C to 65°C (–40°F to 149°F)
Relative humidity (maximum)
Operating 20 percent to 80 percent (non-condensing)
Storage 5 percent to 95 percent (non-condensing)
Maximum vibration
Operating 0.26 Grms
Storage 2.20 Grms
Maximum shock
Operating 40 G
Storage 105 G
Altitude
Operating –15.2 m to 3048 m (–50 to 10,000 ft)
Storage –15.20 m to 10,668 m (–50 ft to 35,000 ft)
Airborne contaminant level G1 or lower as defined by ANSI/ISA-S71.04-1985
54
