Dell OptiPlex 7071 Tower - Installing the Optical Disk Drive

Steps
1. Lay the computer on the right side.
2. Disconnect the data and power cables from the ODD.
3. Push the securing tab to release the ODD from the chassis.
4. Slide and remove the ODD from the ODD slot.
Installing the Optical Disk Drive
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the Optical Disk Drive and provide a visual representation of the installation procedure.
24
Disassembly and reassembly
