Table 33. Ports and Connectors
Feature Specification
Audio:
• one line-out connector
• one audio input/microphone port
• one headphone port
Network adapter one RJ45 connector
USB 2.0 four
USB 3.0 four
Video 15-pin VGA connector
HDMI one 19-pin output port
Media card reader one 8-in-1 slot
Table 34. Power
Feature Specification
Frequency 50 Hz – 60 Hz
Voltage 100 VAC – 240 VAC
Input current:
90 VAC maximum 2.90 A
180 VAC maximum 1.45 A
Coin-cell battery 3 V CR2032 lithium coin cell
Table 35. Camera (optional)
Feature Specification
Image resolution 1.3 megapixel
Video resolution HD (720p)
Diagonal viewing angle 60 degrees
Rotational angle +1 degree to -10 degrees
Table 36. Stand
Feature Specification
Tilt –5 degrees to 30 degrees
Articulating stand –5 degrees to 60 degrees
75
