Disassembly and reassembly
Side cover
Removing the side cover
1 Follow the procedure in Before working inside your computer.
2 To remove the cover:
a Slide the release latch on the back side of your system until it gives a click sound to unlock the side cover [1].
b Slide and lift the side cover from the system [2].
Installing the side cover
1 Place the cover on the computer and slide the cover towards the front of the system [1] until it clicks into place [2].
3
Disassembly and reassembly 11
