Installing the hard drive assembly
1 Align the tabs on the hard drive assembly with the slots on the chassis at 30 degree angle .
2 Press the hard drive assembly so that it gets secured to the hard drive and optical drive cage [1].
3 Connect the hard drive data cable and hard drive power cable to the connectors on the hard drive [2,3]
