Installing heat sink fan
1 Place the heat sink fan on the heat sink [1].
2 Tighten the screws (4) to secure the heat sink fan over the heat sink [2].
NOTE
: Tighten the screws in a sequential order (1,2,3,4) as mentioned on the system board.
3 Connect the heat sink fan cable to the connector on the system board [3].
Disassembly and reassembly
39
