Installing heat sink
1 Place the heat sink on the processor and align the screws of the heat sink with the holders on the system board [1].
2 Tighten the captive screws to secure the heat sink to the system board [2].
Replace the screw in the sequential order (1,2,3,4) as printed on the system board.
Disassembly and reassembly
41
