About this task

NOTE: Ensure that the display hinges are opened to the maximum before replacing the display assembly on the palm-rest

and keyboard assembly.

The following images indicate the location of the display assembly and provide a visual representation of the installation

procedure.

Removing and installing Field Replaceable Units (FRUs) 67
