3. Remove the battery.
4. Remove the system board.
NOTE: The system board can be removed with the following components attached:
● heat sink
● fans
● solid-state drive
5. Remove the power button with fingerprint reader.
About this task
The following images indicate the location of the keyboard and provide a visual representation of the removal procedure.
Figure 48. Removing the keyboard
Removing and installing Field Replaceable Units (FRUs)
67
