Table 32. System setup options—Storage menu
Storage
SATA/NVMe Operation
SATA/NVMe Operation Sets the operating mode of the integrated SATA hard drive controller.
By default, the RAID ON option is selected. The storage device is configured to
support RAID functions.
Storage Interface Displays the information of various onboard drives.
Port Enablement Enables or disables the M.2 PCIe SSD option.
By default, the M.2 PCIe SSD–0 option is enabled.
SMART Reporting
Enable SMART Reporting When enabled, the BIOS can receive analytical information from the integrated
devices and send notifications during startup about possible future failure of the
hard drive.
By default, the SMART Reporting option is disabled.
Drive Information Displays the information of onboard drives.
Table 33. System setup options—Display menu
Display
Display Brightness
Brightness on battery power Enables to set the screen brightness when the computer is running on battery
power.
By default, the screen brightness is set to 50 when the computer is running on
battery power.
Brightness on AC power Enables to set the screen brightness when the computer is running on AC power.
By default, the screen brightness is set to 100 when the computer is running on
AC power.
Touchscreen Enables or disables the touch screen option.
By default, the Touchscreen option is enabled.
Full Screen Logo Enables or disables the computer to display a full-screen logo, if the image
matches screen resolution.
By default, the Full Screen Logo option is disabled.
Table 34. System setup options—Connection menu
Connection
Wireless Device Enable
WLAN Enables or disables the internal WLAN device.
By default, the WLAN option enabled.
Bluetooth Enables or disables the internal Bluetooth device.
By default, the Bluetooth option enabled.
Enable UEFI Network Stack Enables or disables the UEFI Network Stack and controls the onboard LAN
Controller.
By default, the Enable UEFI Network Stack option is enabled.
Wireless Radio Control
82 BIOS Setup
