Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available
on the monitor.
NOTE:
This monitor supports High-Speed Certified USB 2.0 interface.
Transfer Speed 4-pin Side of the Connector
High speed 480 Mbps
Full speed 12 Mbps
Low speed 1.5 Mbps
USB Upstream Connector
Pin Number Data Rate
1 DMU
2 VCC
3 DPU
4 GND
USB Downstream Connector
Pin
Number
Data Rate
1 VCC
About Your Monitor  19
