22  About Your Monitor
Resolution Specifications
Model number Dell P1914S monitor
Scan range
• Horizontal
• Vertical
30 kHz to 81 kHz (automatic)
56 Hz to 76 Hz (automatic)
Maximum preset
resolution
1280 x 1024 at 60 Hz
Electrical Specifications
Model number Dell P1914S monitor
Video input signals • Analog RGB: 0.7 Volts ± 5 %, 75 ohm input
impedance
• Digital DVI-D TMDS, 600 mV for each dierential
line, positive polarity at 50 ohm input impedance
• DP 1.2 signal input support*
Synchronization
input signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on
green)
AC input voltage /
frequency / current
100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/1.2 A
(Max.)
Inrush current 120 V: 30 A (Max.)
240 V: 60 A (Max.)
*Supports DP1.2 (CORE) specification. Excludes High Bit Rate 2 (HBR2), Fast AUX
transaction, Multi-stream transport (MST), 3D stereo transport , HBR Audio (or
high data rate audio).
