16 | About Your Monitor
Displayport port
Pin number 20-pin side of theconnected signal cable
1 ML_Lane 3 (n)
2 GND
3 ML_Lane 3 (p)
4 ML_Lane 2 (n)
5 GND
6 ML_Lane 2 (p)
7 ML_Lane 1 (n)
8 GND
9 ML_Lane 1 (p)
10 ML_Lane 0 (n)
11 GND
12 ML_Lane 0 (p)
13 CONFIG1
14 CONFIG2
15 AUX CH (p)
16 GND
17 AUX CH (n)
18 Hot Plug Detect
19 Return
20 DP PWR
